THM Motorised Test Stand
Brand: Kern
Images are representations only.
THM Motorised Test Stand
Brand: KernMotorised test bench with digital display for horizontal force measurement where the highest standards are required.
Features- NEW: Step motor for greatest ease of use (only for KERN THM 500N500S)
- For constant speed from the smallest to the maximum load
- Allows testing at minimum speed and full load
- For higher positioning accuracy. Precise starting and stopping, without run-on, even at high speeds
- Precise adjustment of the process speed using the information shown on the display
- Easy to use
- Efficient working
- Robust design and heavy duty metal construction
- Linear adjustable jaw vice. The clamping vice can be locked and finely adjusted side wards and up/down using the setting wheel (THM 500N500N)
- Repeat function for durability tests
- Digital speed display: shows the displacement speed
- Premium operating panel :
- Digital speed display
- Digital repeat function display
- Control of the test bench using SAUTER AFH PC software
- Figures shows the premium control panel of SAUTER THM 500N500N
- Solid and versatile fixing options of SAUTER force-measuring devices, see accessories
- Suitable for all SAUTER force-measuring devices up to 500 N (not included)
Specifications
Brand
Measuring Capacity (Max)
- 500 N
Speed Range
- 1 - 500 mm/min
Maximum Travelling Distance
- 220 - 240 mm
KERN THM-N Data
- Minimum Distance between Left and Right Object Fastening: 30 mm
- Maximum Travel Length: 220 mm (Protected by Electronic End Switches)
- Overall Dimensions (W x D x H): 550 mm x 170 mm x 345 mm
- Net Weight: approximately 33 kg
KERN THM-S Data
- Maximum Travel Length: 240 mm (Protected by Electronic End Switches)
- Overall Dimensions (W x D x H): 235 mm x 300 mm x 695 mm
- Net Weight: approximately 48 kg
Documentation
Brochures
- Motorised Horizontal Test Stand SAUTER THM-N/THM-S Brochure (English) pdf 240 KB
- Motorised Horizontal Test Stand SAUTER THM-N/THM-S Brochure (French) pdf 247 KB
- Motorised Horizontal Test Stand SAUTER THM-N/THM-S Brochure (German) pdf 248 KB
- Motorised Horizontal Test Stand SAUTER THM-N/THM-S Brochure (Italian) pdf 241 KB
- Motorised Horizontal Test Stand SAUTER THM-N/THM-S Brochure (Spanish) pdf 243 KB
Certifications
Manuals
- Instruction Manual Motorized Test Bench with Stepper Motor - SAUTER TVO-S/THM-S (English) pdf 334 KB
- Instruction Manual Motorized Test Bench with Stepper Motor - SAUTER TVO-S/THM-S (French) pdf 340 KB
- Instruction Manual Motorized Test Bench with Stepper Motor - SAUTER TVO-S/THM-S (German) pdf 405 KB
- Instruction Manual Motorized Test Bench with Stepper Motor - SAUTER TVO-S/THM-S (Italian) pdf 284 KB
- Instruction Manual Motorized Test Bench with Stepper Motor - SAUTER TVO-S/THM-S (Spanish) pdf 339 KB
- Reference Manual KERN Communications Protocol (KCP) pdf 1.8 MB
