TRS-01a is designed particularly for multipoint temperature and humidity measurement systems to measure temperature in rooms where food products are manufactured and stored. It is equipped with RS-485 / Modus RTU communication interface. Measures temperature within the range of -40°C to +85°C. Has a small plastic casing.

TRS-02a is designed for multipoint measurement of temperature by means of a standard Pt100 sensor. In particular it is designed for use with bayonet sensors to be used, for example, in smoke-houses. It may be used with any Pt100 sensors. This module features very good compensation of effect of connection cable resistance on the result of temperature measurement. Non-linear characteristics of the sensor is digitally linearized. It is equipped with RS-485 / Modus RTU communication interface.

TRS-04a is designed for multipoint temperature and humidity measurement systems. In particular it is used for measuring conditions in rooms where food products are manufactured and stored. It is equipped with RS-485 / Modus RTU communication interface.

The TRS-10a is designed to display digital values and short, 4-letter messages. This superior system makes the display flicker when a displayed value is not refreshed. It is a slave device that communicates with the Master device via RS-485 interface with Modbus RTU protocol. The indicator is dedicated to the TRS Temperature Recording System, yet it can cooperate with any superior system equipped with RS-485 link with Modbus RTU protocol.

The TRS-10a is designed to display digital values and short, 4-letter messages. This superior system makes the display flicker when a displayed value is not refreshed. It is a slave device that communicates with the Master device via RS-485 interface with Modbus RTU protocol. The indicator is dedicated to the TRS Temperature Recording System, yet it can cooperate with any superior system equipped with RS-485 link with Modbus RTU protocol.

The TRS-11a is designed for multipoint temperature measurement within the range of -40°C up to +85°C. It is particularly designed to measure temperature in rooms where food products are manufactured and stored. A display located on the front panel enables the reading of current temperature and autonomous operation of the module (without a computer system). It is equipped with RS-485 / Modus RTU communication interface.

The TRS-B1a sound signal device is designed to signal events with a sound or light. It is controlled by means of RS-485 link, which allows for activating of the sound signal (a buzzer with variable tone) and/or light signal (a flickering diode). The module is dedicated to the TRS Temperature Recording System and it is equipped with RS-485 / Modus RTU communication interface. It can be used with other systems where the communication is consistent with the Modbus RTU standard.

TRS-09a is a supporting power supply for the TRS System which supplies stabilized direct voltage 11,5V. It can work in two modes: as a controlled supply (switched on with external voltage 7...12V) or a non-controlled supply. The configuration is selected by means of a link. Current efficiency is 200 mA. The supply is resistant to output voltage short circuit. The device is located in a casing that completely protects it against dust or low pressure streams of water.

TRS-09a is a supporting power supply for the TRS System which supplies stabilized direct voltage 11,5V. It can work in two modes: as a controlled supply (switched on with external voltage 7...12V) or a non-controlled supply. The configuration is selected by means of a link. Current efficiency is 200 mA. The supply is resistant to output voltage short circuit. The device is located in a casing that completely protects it against dust or low pressure streams of water

Recorder SRS-2/4-Z16-B1a is a two-processor device equipped with a real time clock powered with a lithum battery and flash nonvolatile memory (1 MB) to record approx. 40 000 measurements. After re-activating SimCorder Soft all recorded measurements are copied to a PC, and the recorder buffer is emptied. Basic tasks of the device are connection of the TRS System modules network with a PC equipped with RS-232 interface and automatic recording of measurements when the SimCorder Soft (or the computer) is switched off. Built-in RS-232/RS- 485 interface converter, adjusted to the requirements of Modbus RTU protocol, ensures full galvanic isolation between RS-232 interface and RS-485 lines and it can work with any SIMEX devices equipped with a RS-485 standard link. It can also be used for the transmission between devices equipped with RS-485 interface and a computer with RS-232 link.

Recorder SRS-2/4-Z16-B1a is a two-processor device equipped with a real time clock powered with a lithum battery and flash nonvolatile memory (1 MB) to record approx. 40 000 measurements. After re-activating SimCorder Soft all recorded measurements are copied to a PC, and the recorder buffer is emptied. Basic tasks of the device are connection of the TRS System modules network with a PC equipped with RS-232 interface and automatic recording of measurements when the SimCorder Soft (or the computer) is switched off. Built-in RS-232/RS- 485 interface converter, adjusted to the requirements of Modbus RTU protocol, ensures full galvanic isolation between RS-232 interface and RS-485 lines and it can work with any SIMEX devices equipped with a RS-485 standard link. It can also be used for the transmission between devices equipped with RS-485 interface and a computer with RS-232 link.
