Specifications
Connections
- 4 pin industrial DC power socket 9-50V DC, reverse polarity protection, voltage surge/transient protection
- 2 x RP-SMA for WiFi
- 4 x SMA for 5G/LTE
- 1 x GNSS
- DIN rail mounting slot in the back and on both sides
- Maximum power consumption 18W
Physical Propertys
- 132 mm x 44.2 mm x 95.1 mm / 5.19” x 1.74” x 3.74” (W x H x L)
- Protection class IP30
- Weight 533 g / 1.17 lbs (net weight article)
- Storage temperature -40 °C … +75 °C / -40 °F … +167 °F
- Operating temperature -40 °C … +75 °C / -40 °F … +167 °F
- Power supply operating temperature -10 °C ... +40 °C /14°F … +104 °F
- Power storage temperature -20 °C ... +70 °C /-4°F … +158 °F
