HD35RE – Wireless Data Logger System
Brand: Delta OHM S.R.L.HD35RE repeaters: the repeaters are devices able to act as a bridge between the base unit HD35AP and the remote data loggers HD-35ED.
They allow the increase of the communication distance among the data loggers and the base unit. More repeaters can be interposed between a data logger and the base unit to further increase the communication distance.
Specifications
Brand
Pt100 / Pt1000 Measuring Range
- -200 to +650° C
Pt100 / Pt1000 Resolution
- 0.1° C
Pt100 / Pt1000 Accuracy
- ± 0.1° C (excluding probe error)
Pt100 / Pt1000 Sensor Coefficient
- a=0.00385°C-1
Pt100 / Pt1000 Connection
- 2, 3 or 4-Wires
Thermocouple Type
- K, J, T, N, E.
- The inputs are not isolated, use thermocouples with isolated hot junction
Thermocouple Measuring Range
- Type K: -200 to +1370° C
- Type T: -200 to +400° C
- Type E: -200 to +750° C
- Type J: -100 to +750° C
- Type N: -200 to +1300° C
Thermocouple Accuracy (Excluding Probe Error)
- Type K: ± 0.1° C (600° C)
- Type J: ± 0.1° C
- Type T: ± 0.1° C
- Type N: ± 0.1° C (600° C)
- Type E: ± 0.1° C (300° C)
Thermocouple Resolution
- 0.1° C
0/4 to 20 mA Input Shunt Resistance
- Internal (50 W)
0/4 to 20 mA Input Resolution
- 16 bits
0/4 to 20 mA Input Accuracy
- ± 2 µA
0 to 50 mV, 0 to 1 V and 0 to 10 V Inputs (0 to 10 V only in HD35EDWH) Input Resistance
- 100 MW
0 to 50 mV, 0 to 1 V and 0 to 10 V Inputs (0 to 10 V only in HD35EDWH) Resolution
- 16 bits
0 to 50 mV, 0 to 1 V and 0 to 10 V Inputs (0 to 10 V only in HD35EDWH) Accuracy
- ± 0.01 % Full Scale
Input for Counting the Switchings of a Voltage-Free Contact Switching Frequency
- 50 Hz max
Input for Counting the Switchings of a Voltage-Free Contact Hold Time
- 10 ms min.
Potentiometer
- Typically 10 kW
Potentiometer Resolution
- 16 bits
Potentiometer Accuracy
- ± 0,01 % Full Scale
- Food and Warehouses
- Pharmaceutical, Medical Laboratories, Clean Rooms
- Museums, Buildings and Public places
- Air Conditioning
- Renewable Energy
- Agriculture and Greenhouses
- Meteorology and Hydrology
- Industrial Processes
