Thermowell Material
- Ceramic C610 Max. temperature +1500 C, gas-tight, medium to good thermal shock resistance
- Ceramic C799 Max. temperature +1600 C, gas-tight, medium thermal shock resistance
- Other materials on request
Tolerances Thermocouple - IEC 60584
- Type J tolerance class 1 = -40° to +375° C ± 1.5 C, +375° to +750° C ± 0.004 x t
- Type K and N tolerance class 1 = -40° to +375° C ± 1.5 C, +375° to 1000° C ± 0.004 x t
- Type R and S tolerance class 1 = 0° to +1100 C ± 1 C, 1100° to 1600 C ± [1+0.003(t-1100)] C
Temperature Range
- -200 to +1700° C
- Depending on thermocouple type
- Thermowell material and neck pipe length
Approvals
- ATEX
- IECEx
- EAC EMC
- Metrological Pattern Approval
Quality Certificate
- ISO 9001:2015 and ISO 14001:2015 issued by DNV
IP Rating
- IP65
- Higher IP rating on request
